Interior
Galley - Forward
Fwd Cabin - Four (4) Place Double Club w/ Pull-Out Tables
Aft Cabin - Three (3) Place Divan Opposite a Two (2) Place Club w/ Pull-Out Table
Lavatory- Aft Belted LAV
Galley Equipment - Microwave and Coffee Maker
Weights
Gross Weight (RAMP) - 39,000 lbs.
MAX Takeoff - 38,850 lbs.
MAX Landing - 37,750 lbs.
MAX Zero Fuel - 27,000 lbs.
MAX Fuel Capacity - 27,000 lbs.
Basic Operating - 24,274 lbs.
Entertainment
Display / TV Monitor(s) - Dual 20.0” LCD Bulkhead Monitors
Airshow System - Airshow 4000 w/ Worldwide Package
Cabin Management System - Rockwell Collins Ethernet System
Phone System - ICG NxtLink ICS-220A Iridium System
Other Features - Dual CD / DVD Player
Galley Equipment - Microwave and Coffee Maker
Avionics
EFIS (Electronic Flight Instrument System) Four-Tube Rockwell Collins AFD-5220
FMS (Flight Management System) Dual Rockwell Collins FMC-5000
CDU (Central Display Unit) Dual Rockwell Collins CDU-5200
GPS (Global Positioning System) Dual Rockwell Collins GPS- 4000S
ADC (Air Data Computer) Dual Rockwell Collins ADC-3000 NAV (Navigation Radio) Dual Rockwell Collins NAV-4000
RIU (Radio Interface Unit) Dual Rockwell Collins RIU-4000
DME (Distance Measuring Equipment) Dual Rockwell Collins DME-4000
ADF (Automatic Direction Finder) Dual Rockwell Collins NAV-4000 A/P (Autopilot) Single Rockwell Collins Integrated System
VHF COM (Very High Freq. Communications) Triple Rockwell Collins VHF-4000 w/ XM Weather
HF COM (High Freq. Communications) Dual Rockwell Collins HF-9041A w/ SELCAL
SATCOM (Satellite Communications) Single ICG NxtLink ICS-220A Iridium System
WRADAR (Weather Radar) Single Rockwell Collins RTA-854
RADAR ALT (Radar Altimeter) Single Rockwell Collins ALT-4000
XPNDR (Transponder) Dual Rockwell Collins TDR-94D w/ Mode S
GPWS (Ground Proximity Warning System) Single Rockwell Collins TAS-5000
TCAS (Traffic Collision Avoidance System) Single Rockwell Collins TTR-4000 TCAS II
CVR (Cockpit Voice Recorder) Single L3 Technologies FA2100 SSCVR
FDR (Flight Data Recorder) Single L3 Technologies FA2100 SSFDR
ELT (Emergency Locator Transmitter) Single ACR Artex C406-N
Other Notable Features
SB 100-23-06 – Datalink and SELCAL System
SB 100-23-21 – Euro Control Datalink (“Link 2000+”)
SB 100-34-06 – Turbulence Weather Radar Detection
SB 100-34-10 – FMS V-Speed
SB 100-34-11 – Lower TCAS Directional Antenna
SB 100-34-23 – GPS-4000S w/ Wide Area Augmentation System (“WAAS”)
SB 100-34-28 – Automatic Dependent Surveillance – Broadcast (“ADS-B”) Out
Enhanced Map Overlays Enhanced DBU 5000 Functionality
ProLine 21 Advanced; ADS-B Out Version 2.0
